DCR-4 Remote (addon to existing controller)

$3,269.75
Item
73745
DCR-4 Remote (addon to existing controller)
DCR-3 Remote (addon to existing controller)

Information below illustrates information about the kit that contains this remote.

KEY FEATURES: MC5 Remote Starter Kit

SIMPLE No programming required, and less than 15 seconds from Off to Ready-to-Fire
1) SELECT: turn Remote selector switch to EB (electrical blasting/electric breech) or ST (shock tubes)
2) CONNECT: connect blasting load after Link LED starts flashing
3) LINK: generate a Secure Link by pressing, and immediately releasing Arm button; wait for solid Link LED
4) ARM: click and maintain Arm button; wait for the ready-to-fire vibration, and Arm LED (~5 to 7 seconds)
5) FIRE: maintain Arm, and click Fire button; once fired, release both buttons

SECURE Factory-paired set only share half-duplex communication with each other, and only after linking
Requires two separate and distinct operations to fire, and cannot fire until fully charged
If the Arm button is released (prior to pressing Fire) the Remote instantly aborts, and returns to a safe state
The Remote auto aborts if communication is lost with the Controller for a specific period of time
A Built-In Test confirms safety and functionality before connecting the explosive train; locks-out controls on a fault

VERSATILE Very small, tac-bot mountable Remote; quite handy for disruptors too - easily moved between platforms
Ambidextrous, one-handed Controller; fits in radio pouch

DCR Fires Nonel (single, or dual), Electrical, or an Electric Breech
Remote has unique, tri-mode power options: CR123A battery; external battery; or AC Adapter
Remote has a built in smart charger for recharging its battery in as little as two hours
Displays blasting resistance on a Geometric-scale bar graph, from 1 to 400 (when Remote is in EB Mode)

POWERFUL 360 VDC @ 12 Joules (average) Firing Energy
Internally Shunted and load protected
Fires up to two shock tubes, up to 75 EBCs, or an Electric Breech; without changing or rotating blasting terminals

RADIO FEATURES
Modulation FHSS 900 MHz (also available in 2.4 GHz - it is up to the customer to request proper frequency)
Security 128 Bit AES; Rolling Code at Link, and after each use Error Correction 16 Bit CRC
TX Output Power 250mW
Range* Indoor Up to 700' Urban Up to 1600' Outdoor/LOS Up to 4000
FCC ID MCQ-XB900HP (US 900MHz license, Non-US licensing available upon request)
KIT FEATURES DCR-­1
                                     Remote TRC-1                                       Controller
Size (without antenna) 3.25 x 4.25 x 1.75 (82 x 108 x 45mm      2.8 x 5.25 x 1.4 (71 x 133 x 35mm)
Weight (including battery 16.25 ounces (354g)                       10 ounces (284g)
Enclosure Desert Tan powder coated aluminum; black glass-filled nylon
Ingress protection is IP65 Compliant
Same
Primary Power Source CR123 Battery
Battery Life Up to 3 days standby, or up to 100 shots before recharging 100+ shots (conservative)
Alternate Power Source 9V Battery Adapter (provides at least 1 shot) or AC Adapter NA
Kit includes: (1) DCR Remote; (1) TRC Controller; (2) 1/4-wave articulated antennas; (1) ea. AC & 9V adapters;
Instruction Guide; and (1) form-fitted, rugged case

FIRING CAPACITY
Nonel Up to two shock tubes (2.85mm or 3mm shock tubes fire simultaneously)
Nonel Ignition Method Two Firebolt II radial-electrode plasma emitters (easily replaceable, 1/8" Phone Plug style)
Electrical Capacity Up to 75 standard EBCs (up to 400 ohm total load)
Electric Breech Safely fires an electric breech in under 100ms releases even if FIRE is maintained
